Spray Granulation Dryer
Description of Spray Granulation Dryer:
This PZ type spray granulation dryer has integrated the spraying, granulating, and drying into one body. A series of new technologies have been used in the process of its manufacture, such as strengthened bricks, heat transfer, internal classification, internal material returning, internal crushing, and so on.
It has features of high productivity, easy operation, energy saving, simple process flow, etc.
Technical Parameters of PZ Series Spray Granulation Dryer
| Specification | Output (t/h) | Rotating speed of cylinder(r/min) | Cylinder slope (%) | Inlet temperature | Slurry temperature | Moisture of slurry | Motor power (kw) | Weight (t) |
| Φ3.0×12 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 71.0 |
| Φ3.0×13 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 75.3 |
| Φ4.0×12 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 110 | 105 |
| Φ4.0×14 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 130 | 109.8 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 160 | 151 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 185 | 160 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 220 | 184 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 250 | 196 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 280 | 255 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 315 | 265 |
Note:
1. The moisture of its products is no more than 1.5%.
2. 1-4mm particle size is more than 90%.
